Description
|
| Product Description
|
1-port IEEE1284 Parallel Universal PCI Board
|
| Parallel Communication
|
| Interface
|
IEEE1284
|
| Controller
|
SUNIX SUN1989
|
| Bus
|
Universal PCI 64/32bit 3.3V/5V PCI Ver 3.0, 2.3, 2.2, 2.1
|
| No. of Port
|
1-port
|
| IRQ & IO
|
Assigned by System
|
| FIFO
|
16 byte (Hardware)
|
| Signal
|
SPP/ECP/EPP/BPP
|
| Speed
|
Maximum 1.8MBps
|
| PCB connector
|
DB25 Female
|
| Driver Support
|
| Microsoft Client
|
Windows XP/Vista/7 (X86/X64)
|
| Microsoft Server
|
Windows 2000/2003/2008 (X86/X64)
|
| Microsoft Embedded
|
Windows XP Embedded/POS Ready 2009/Embedded System 2009
|
| Linux
|
Linux 2.4.x / 2.6.x
|
| DOS
|
DOS
|
| Regulatory Approvals
|
| Hardware
|
EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 Class B, BSMI: CNS13438, C-Tick: CISPR22 AS/NZS, RoHS
|
| Software
|
Microsoft WHQL Windows
|
| • Microsoft Client: XP/Vista/7 (X86/X64)
|
| • Microsoft Server: 2000/2003/2008 (X86/X64)
|
| Environment
|
| Operation Temperature
|
0 to 60°C (32 to 140°F)
|
| Operation Humidity
|
5 to 95% RH
|
| Storage Temperature
|
-20 to 85°C (-4 to 185°F)
|
| Dimension
|
| PCB Dimension
|
120 x 66 mm
|
| Bracket
|
Standard 121 mm
|
| Bracket Space
|
1
|
|
|
|
| Note:
|
| * Do not support LPT Key Locker Parallel device.
|
| * LPT port does not support legacy 278/378 ISA address under Windows nor Linux operation systems, but only DOS mode.
|
